P06D2 Code - 5V Reference 5 Circuit
Quick Answer
The Engine Control Module (ECM) has four (5) internal 5 Volt reference circuits (Some models have two (2) internal 5 Volt reference circuits). Common causes include Faulty Sensor on 5 Volt circuit, Sensor on 5 Volt circuit harness is open or shorted, Sensor on 5 Volt circuit poor electrical connection. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
- What it means
- P06D2 indicates 5V Reference 5 Circuit.
- Common causes
- Common causes include Faulty Sensor on 5 Volt circuit, Sensor on 5 Volt circuit harness is open or shorted, Sensor on 5 Volt circuit poor electrical connection.
- Severity
- High - diagnose this code as soon as possible.
- Can I drive?
- Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
Code P06D2 Description
What are the Possible Causes of the DTC P06D2?
- Faulty Sensor on 5 Volt circuit
- Sensor on 5 Volt circuit harness is open or shorted
- Sensor on 5 Volt circuit poor electrical connection
- Faulty Engine Control Module (ECM)
How to Fix the DTC P06D2?
Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.
What is the Cost to Diagnose the Code?
Labor: 1.0
To diagnose the P06D2 code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.
Need more information about the P06D2 code?
Need more information on how to fix the P06D2 code? Get Access to Factory Service Manuals
Need Help with the Code?
Get the P06D2 code diagnosed by a professional: Find a repair shop in your area
Information for Specific Makes
- P06D2 Buick — 5V Reference 5 Circuit
- P06D2 Cadillac — 5V Reference 5 Circuit
- P06D2 Chevrolet — 5V Reference 5 Circuit
- P06D2 GMC — 5V Reference 5 Circuit
Frequently Asked Questions about P06D2 Code
What does the OBDII code P06D2 mean?
1. P06D2 indicates an issue with the 5V Reference 5 Circuit, which supplies a stable 5-volt reference signal to various vehicle sensors. 2.
What are the common symptoms of the P06D2 code?
Symptoms may include the check engine light turning on, poor engine performance, erratic sensor readings, or failure of certain systems like the throttle or transmission. 3.
What causes the P06D2 code to appear?
Common causes include a short or open circuit in the 5V reference wiring, a faulty sensor using the 5V reference, or a malfunctioning engine control module (ECM). 4.
Can I drive my car with a P06D2 code?
Driving with a P06D2 code is not recommended, as it can lead to improper engine performance or further damage to the vehicle. 5.
How do I diagnose a P06D2 code?
Start by inspecting the 5V reference wiring and connectors for damage, check for faulty sensors connected to the circuit, and test the ECM if needed. 6.
What sensors rely on the 5V reference circuit?
Sensors such as the throttle position sensor (TPS), manifold absolute pressure (MAP) sensor, and crankshaft position sensor may use the 5V reference circuit. 7.
How do I fix the P06D2 code?
Repairs may involve repairing or replacing damaged wiring, replacing a faulty sensor, or reprogramming or replacing the ECM if it is defective. 8.
Can a bad ground connection cause the P06D2 code?
Yes, a poor ground connection can disrupt the 5V reference circuit and trigger the P06D2 code. 9.
How much does it cost to repair a P06D2 code?
Repair costs vary depending on the issue but may range from $50 for simple wiring repairs to over $1,000 if the ECM needs replacement. 10.
Will clearing the code fix the P06D2 issue?
Clearing the code without addressing the root cause will not fix the problem, and the code is likely to return.
