AutoCodes – Toyota – U0140 2013 Toyota RAV4

U0140 2013 Toyota RAV4 Code - Lost Communication with Main Body ECU

Quick Answer

The Controller Area Network (CAN) is a standard bus system in vehicles that enables the connection of automotive devices without the need for a host computer. Common causes include Faulty Controller Area Network (CAN) Communication System, Faulty Main Body ECU, Main Body ECU harness is open or shorted. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

What it means: U0140 2013 Toyota RAV4 indicates Lost Communication with Main Body ECU.
Common causes: Common causes include Faulty Controller Area Network (CAN) Communication System, Faulty Main Body ECU, Main Body ECU harness is open or shorted.
Severity: High - diagnose this code as soon as possible.
Can I drive?: Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

Save to My Repairs My Repairs

AI answers can be wrong. Verify repairs with testing. Open full chat

Code Popularity 272

How popular is this code, among other codes? Low

Repair Importance Level

Urgent (Diagnose now) (3 / 3)

Repair Difficulty Level

Advanced (Pro) (3 / 3)

What is this?

Table of contents Created and updated by William Orellana on Mar 26, 2023

Description
Possible Causes
How To Fix
Tech Notes
Cost to Diagnose
FAQs
Comments
Add Comment

💬 Need more help? Ask Coddy for instant answers — it's free!

Code U0140 2013 Toyota RAV4 Description

The Controller Area Network (CAN) is a standard bus system in vehicles that enables the connection of automotive devices without the need for a host computer. The exchange of operating information and commands among devices is facilitated by pre-programmed information about the required message exchange on the serial data circuits. Communication is carried out using two dedicated wires, known as CAN high and CAN low, with both lines carrying 2.5V when the CAN bus is in idle mode. During the transmission of data bits, the CAN high line increases to 3.75V while the CAN low drops to 1.25V, creating a 2.5V differential between the lines. Since communication relies on a voltage differential between the two bus lines, the CAN bus is NOT sensitive to inductive spikes, electrical fields, or other noise. The Diagnostic Trouble Code (DTC) sets when a periodic message from the Main Body ECU has not been received.

Pictures shown may vary from actual

OBDII Code U0140 2013 Toyota RAV4 - Lost Communication with Main Body ECU - AutoCodes.com — U0140 2013 Toyota RAV4 Code - Lost Communication with Main Body ECU

What does this mean?

What are the Possible Causes of the DTC U0140 2013 Toyota RAV4?

Faulty Controller Area Network (CAN) Communication System
Faulty Main Body ECU
Main Body ECU harness is open or shorted
Main Body ECU circuit poor electrical connection

How to Fix the DTC U0140 2013 Toyota RAV4?

Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.

What does this mean?

Code Tech Notes

When there are problems with the way different systems in a vehicle communicate with each other using a technology called Controller Area Network (CAN) communication, Diagnostic Trouble Codes (DTC) are displayed. These codes can be caused by issues with the main bus or branch of the communication network, or with the Electronic Control Units (ECUs) and sensors that make up the different systems. If you see code for both the CAN communication problems and internal or power source problems at the same time, you should focus on fixing the internal or power source problems first.

What is the Cost to Diagnose the Code?

Labor: 1.0

To diagnose the U0140 2013 Toyota RAV4 code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.

Need more information about the U0140 2013 Toyota RAV4 code?

Need more information on how to fix the U0140 2013 Toyota RAV4 code? Get Access to Factory Service Manuals

Need Help with the Code?

Get the U0140 2013 Toyota RAV4 code diagnosed by a professional: Find a repair shop in your area

About the author: William Orellana is a Master Mechanic and Mechanical Engineer with over 30 years of experience diagnosing and repairing vehicles. Learn more about his background.

Frequently Asked Questions about U0140 2013 Toyota RAV4 Code

1. What does the OBDII code U0140 for a 2013 Toyota RAV4 mean?

The U0140 code indicates a communication problem between the vehicle's main body Electronic Control Unit (ECU) and other control modules.

2. What are the common symptoms of the U0140 code in a 2013 Toyota RAV4?

Common symptoms include dashboard warning lights, loss of functionality in various vehicle systems (such as power windows, door locks, lights), and potential drivability issues.

3. What are some possible causes of the U0140 code in a 2013 Toyota RAV4?

Potential causes include damaged wiring or connectors, a faulty main body ECU, issues with the communication network (such as the Controller Area Network or CAN bus), or a disconnected or malfunctioning control module.

4. How can I diagnose the U0140 code in my 2013 Toyota RAV4?

Diagnosing the U0140 code typically involves using a professional OBDII scanner to retrieve the code and performing a thorough inspection of the wiring, connectors, and control modules related to the main body ECU.

5. Can I still drive my 2013 Toyota RAV4 with the U0140 code present?

It is generally not recommended to drive your vehicle with the U0140 code active, as it can lead to potential safety issues and further damage to the vehicle's systems.

6. How can the U0140 code in a 2013 Toyota RAV4 be repaired?

Repairing the U0140 code may involve fixing any damaged wiring or connectors, replacing the main body ECU or faulty control modules, and ensuring proper communication between all modules on the network.

7. Is it necessary to reset the U0140 code after repairs are made on a 2013 Toyota RAV4?

Yes, it is important to clear the U0140 code using an OBDII scanner after performing repairs to ensure the issue has been resolved and prevent it from reoccurring.

8. Are there any specific recalls or technical service bulletins related to the U0140 code in a 2013 Toyota RAV4?

It is advisable to check with a Toyota dealership or online resources for any relevant recalls or technical service bulletins related to the U0140 code in a 2013 Toyota RAV4.

9. Can a DIY enthusiast fix the U0140 code issue in a 2013 Toyota RAV4?

While some basic troubleshooting and repairs can be performed by a knowledgeable DIY enthusiast, diagnosing and repairing complex electrical issues like the U0140 code may require professional expertise and specialized tools.

10. How can I prevent the U0140 code from occurring in my 2013 Toyota RAV4 in the future?

To prevent the U0140 code from occurring, it is essential to regularly inspect and maintain the vehicle's electrical system, including checking for loose connections, damaged wiring, and ensuring all control modules are functioning properly.
