P0C52 GMC Code - Drive Motor 1 Position Sensor Circuit 1 Low Voltage

Quick Answer

The drive motor position sensor is monitored by the motor control module. Common causes include Faulty Drive Motor 1 Position Sensor, Drive Motor 1 Position Sensor harness is open or shorted, Drive Motor 1 Position Sensor circuit poor electrical connection. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

What it means: P0C52 GMC indicates Drive Motor 1 Position Sensor Circuit 1 Low Voltage.
Common causes: Common causes include Faulty Drive Motor 1 Position Sensor, Drive Motor 1 Position Sensor harness is open or shorted, Drive Motor 1 Position Sensor circuit poor electrical connection.
Severity: High - diagnose this code as soon as possible.
Can I drive?: Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

Save to My Repairs My Repairs

AI answers can be wrong. Verify repairs with testing. Open full chat

Code Popularity 1,312

How popular is this code, among other codes? Low

Repair Importance Level

Urgent (Diagnose now) (3 / 3)

Repair Difficulty Level

Advanced (Pro) (3 / 3)

What is this?

Table of contents Created and updated by William Orellana on Aug 07, 2022

Description
Possible Causes
How To Fix
Cost to Diagnose
FAQs
Comments
Add Comment

💬 Need more help? Ask Coddy for instant answers — it's free!

Code P0C52 GMC Description

The drive motor position sensor is monitored by the motor control module. The motor control module monitors the angular position, speed, and direction of the drive motor rotor based upon the signals of the resolver-type position sensor. The position sensor contains a drive coil, two driven coils, and an irregular-shaped metallic rotor. The metallic rotor is mechanically attached to the shaft of the drive motor. At vehicle ON, the motor control module outputs a 7 V AC, 10 kHz excitation signal to the drive coil. The drive coil excitation signal creates a magnetic field surrounding the two driven coils and the irregular-shaped rotor. The motor control module then monitors the two driven coil circuits for return signals, often referred to as Sine and Cosine waveforms, abbreviated SIN and COS. The position of the irregular metallic rotor causes the magnetically induced return signals of the driven coils to vary in size and shape. A comparison of the two driven coil signals allows the motor control module to determine the exact position, speed, and direction of the drive motor rotor. The drive motor 1 position sensor is serviceable separately from the drive motor assembly. The Diagnostic Trouble Code (DTC) will be set when the circuit voltage is less than 0.5 V.

OBDII Code P0C52 GMC - Drive Motor 1 Position Sensor Circuit 1 Low Voltage - AutoCodes.com — P0C52 GMC Code - Drive Motor 1 Position Sensor Circuit 1 Low Voltage

What does this mean?

What are the Possible Causes of the DTC P0C52 GMC?

Faulty Drive Motor 1 Position Sensor
Drive Motor 1 Position Sensor harness is open or shorted
Drive Motor 1 Position Sensor circuit poor electrical connection
Faulty Power Inverter Module

How to Fix the DTC P0C52 GMC?

Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.

What is the Cost to Diagnose the Code?

Labor: 1.0

To diagnose the P0C52 GMC code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.

Need more information about the P0C52 GMC code?

Need more information on how to fix the P0C52 GMC code? Get Access to Factory Service Manuals

Need Help with the Code?

Get the P0C52 GMC code diagnosed by a professional: Find a repair shop in your area

Information for Specific GMC Models

P0C52 2016 GMC Sierra — Drive Motor Position Sensor Circuit 1 Low Voltage
P0C52 2017 GMC Sierra — Drive Motor Position Sensor Circuit 1 Low Voltage
P0C52 2018 GMC Sierra — Drive Motor Position Sensor Circuit 1 Low Voltage

About the author: William Orellana is a Master Mechanic and Mechanical Engineer with over 30 years of experience diagnosing and repairing vehicles. Learn more about his background.

Frequently Asked Questions about P0C52 GMC Code

1. What are the common symptoms of OBDII code P0C52 GMC Drive Motor 1 Position Sensor Circuit 1 Low Voltage?

- Common symptoms include poor acceleration, reduced power, and possibly an illuminated check engine light.

2. What are the possible causes of OBDII code P0C52 GMC?

- The code may be triggered by a faulty drive motor 1 position sensor, damaged wiring or connectors in the circuit, or issues with the drive motor itself.

3. How can I diagnose the cause of OBDII code P0C52 GMC?

- To diagnose the issue, you may need to perform a thorough inspection of the drive motor 1 position sensor, check the wiring and connectors for damage, and test the drive motor for proper function.

4. Can I drive my vehicle with OBDII code P0C52 GMC active?

- It is not recommended to drive your vehicle with this code active, as it can lead to further damage and potential safety issues. It's best to address the problem promptly.

5. How can I repair OBDII code P0C52 GMC Drive Motor 1 Position Sensor Circuit 1 Low Voltage?

- Repair may involve replacing the drive motor 1 position sensor, repairing or replacing damaged wiring or connectors, or addressing any underlying issues with the drive motor.

6. Will resetting the OBDII code P0C52 GMC make it go away permanently?

- Resetting the code may temporarily turn off the check engine light, but if the underlying issue is not addressed, the code is likely to return.

7. Can a DIYer fix OBDII code P0C52 GMC, or should I take it to a professional mechanic?

- Depending on your mechanical skills and knowledge, you may be able to address this code yourself by following repair guides or consulting with professionals if needed.

8. How much does it typically cost to repair OBDII code P0C52 GMC Drive Motor 1 Position Sensor Circuit 1 Low Voltage?

- The cost of repair can vary depending on the cause of the code, the extent of the damage, and whether you choose to fix it yourself or seek professional help.

9. Are there any potential safety concerns associated with OBDII code P0C52 GMC?

- Driving with this code active can potentially affect the performance and safety of your vehicle, so it's important to address the issue promptly.

10. Is it normal for OBDII code P0C52 GMC to reoccur after repair?

- If the underlying issue is not properly addressed during repair, the code is likely to reoccur. It's important to diagnose and fix the root cause to prevent future occurrences.
