AutoCodes – Honda – P0842 2017 Honda CR-V

P0842 2017 Honda CR-V Code - Transmission Fluid Pressure Sensor/Switch 'A' Circuit Low

Quick Answer

The Continuously Variable Transmission (CVT) driven pulley pressure sensor uses a strain gauge. Common causes include Faulty CVT Driven Pulley Pressure Sensor, CVT Driven Pulley Pressure Sensor harness is open or shorted, CVT Driven Pulley Pressure Sensor circuit poor electrical connection. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

What it means: P0842 2017 Honda CR-V indicates Transmission Fluid Pressure Sensor/Switch 'A' Circuit Low.
Common causes: Common causes include Faulty CVT Driven Pulley Pressure Sensor, CVT Driven Pulley Pressure Sensor harness is open or shorted, CVT Driven Pulley Pressure Sensor circuit poor electrical connection.
Severity: High - diagnose this code as soon as possible.
Can I drive?: Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

Save to My Repairs My Repairs

AI answers can be wrong. Verify repairs with testing. Open full chat

Code Popularity 280

How popular is this code, among other codes? Low

Repair Importance Level

Urgent (Diagnose now) (3 / 3)

Repair Difficulty Level

Advanced (Pro) (3 / 3)

What is this?

Table of contents Created and updated by William Orellana on Jan 30, 2024

Description
Possible Causes
How To Fix
Cost to Diagnose
FAQs
Comments
Add Comment

💬 Need more help? Ask Coddy for instant answers — it's free!

Code P0842 2017 Honda CR-V Description

The Continuously Variable Transmission (CVT) driven pulley pressure sensor uses a strain gauge. The output voltage changes depending on the driven pulley pressure. The Powertrain Control Module (PCM) sends a 5 V reference voltage to the sensor through a pull-up resistor. When the driven pulley pressure is low, the sensor resistance decreases and the PCM detects a low signal voltage. Conversely, when the driven pulley pressure is high, the sensor resistance increases, and the PCM detects a high signal voltage. If the CVT driven pulley pressure sensor signal voltage is a specified voltage for a set time, the PCM detects a malfunction and stores a Diagnostic Trouble Code (DTC).

OBDII Code P0842 2017 Honda CR-V - Transmission Fluid Pressure Sensor/Switch 'A' Circuit Low - AutoCodes.com — P0842 2017 Honda CR-V Code - Transmission Fluid Pressure Sensor/Switch 'A' Circuit Low

What does this mean?

What are the Possible Causes of the DTC P0842 2017 Honda CR-V?

Faulty CVT Driven Pulley Pressure Sensor
CVT Driven Pulley Pressure Sensor harness is open or shorted
CVT Driven Pulley Pressure Sensor circuit poor electrical connection
Faulty Powertrain Control Module (PCM)

How to Fix the DTC P0842 2017 Honda CR-V?

Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.

What is the Cost to Diagnose the Code?

Labor: 1.0

To diagnose the P0842 2017 Honda CR-V code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.

Need more information about the P0842 2017 Honda CR-V code?

Need more information on how to fix the P0842 2017 Honda CR-V code? Get Access to Factory Service Manuals

Need Help with the Code?

Get the P0842 2017 Honda CR-V code diagnosed by a professional: Find a repair shop in your area

About the author: William Orellana is a Master Mechanic and Mechanical Engineer with over 30 years of experience diagnosing and repairing vehicles. Learn more about his background.

Frequently Asked Questions about P0842 2017 Honda CR-V Code

1. What does the OBDII code P0842 mean on a 2017 Honda CR-V?

P0842 indicates a low voltage issue in the Transmission Fluid Pressure Sensor/Switch 'A' circuit, which monitors the pressure of the transmission fluid.

2. What are the common symptoms of code P0842 in a 2017 Honda CR-V?

Symptoms may include harsh or erratic shifting, slipping transmission, the transmission going into limp mode, or the check engine light turning on.

3. What causes the P0842 code on a 2017 Honda CR-V?

Common causes include a faulty transmission fluid pressure sensor, damaged wiring or connectors in the circuit, low transmission fluid level, or contaminated transmission fluid.

4. Can I drive my 2017 Honda CR-V with the P0842 code?

Driving with this code is not recommended, as it can lead to further transmission damage or unsafe driving conditions due to shifting problems.

5. How do I fix the P0842 code on a 2017 Honda CR-V?

Possible fixes include replacing the transmission fluid pressure sensor, repairing or replacing damaged wiring, ensuring the transmission fluid is at the correct level, or flushing and refilling the transmission fluid.

6. How do I diagnose the P0842 code on a 2017 Honda CR-V?

Diagnosis involves using a scan tool to confirm the code, inspecting the sensor and wiring for damage, and checking the transmission fluid level and condition.

7. What is the cost to repair a P0842 code on a 2017 Honda CR-V?

Repair costs can vary, but replacing the transmission fluid pressure sensor typically costs $150 to $300, including parts and labor. Wiring repairs or fluid changes may cost less.

8. Can low transmission fluid cause the P0842 code on a 2017 Honda CR-V?

Yes, low transmission fluid can cause incorrect pressure readings, triggering the P0842 code.

9. How can I prevent the P0842 code from recurring in a 2017 Honda CR-V?

Regularly check and maintain proper transmission fluid levels, use the recommended fluid type, and inspect wiring and sensors during routine maintenance.

10. Does the P0842 code affect fuel efficiency in a 2017 Honda CR-V?

Yes, it can reduce fuel efficiency due to improper transmission operation and increased engine workload.
