C1694 Code - Steering Angle Initialization Incomplete
Quick Answer
This Diagnostic Trouble Code (DTC) is stored when the Television Camera Assembly judges that the maximum Steering Angle has not been memorized (Steering Angle setting is incomplete). Common causes include Steering Angle setting, Faulty Television Camera Assembly. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
- What it means
- C1694 indicates Steering Angle Initialization Incomplete.
- Common causes
- Common causes include Steering Angle setting, Faulty Television Camera Assembly.
- Severity
- High - diagnose this code as soon as possible.
- Can I drive?
- Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
Code C1694 Description
What are the Possible Causes of the DTC C1694?
- Steering Angle setting
- Faulty Television Camera Assembly
How to Fix the DTC C1694?
Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.
What is the Cost to Diagnose the Code?
Labor: 1.0
To diagnose the C1694 code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.
Need more information about the C1694 code?
Need more information on how to fix the C1694 code? Get Access to Factory Service Manuals
Need Help with the Code?
Get the C1694 code diagnosed by a professional: Find a repair shop in your area
Information for Specific Makes
- C1694 Lexus — Steering Angle Initialization Incomplete
- C1694 Toyota — Steering Angle Initialization Incomplete
Frequently Asked Questions about C1694 Code
1. What does the OBDII code C1694 mean?
C1694 indicates that the steering angle initialization process has not been completed or has failed, which is necessary for proper functioning of the vehicle's stability and traction control systems.
2. What are the symptoms of code C1694?
Common symptoms include the illumination of the ABS, traction control, or stability control warning lights, and possible issues with vehicle handling or stability during turns.
3. What causes code C1694?
The most common causes are an incomplete or failed steering angle sensor calibration, a malfunctioning steering angle sensor, low battery voltage, or improper alignment.
4. How do I fix the C1694 code?
Complete the steering angle sensor calibration using an OBDII scan tool capable of performing this function. If the issue persists, inspect and replace a faulty steering angle sensor if necessary.
5. Can I drive with code C1694 active?
While you may still be able to drive, the vehicle’s stability and traction control systems may not function correctly, increasing the risk of losing control in certain conditions.
6. What tools are needed to resolve code C1694?
You will need an OBDII scan tool with steering angle sensor calibration capabilities and possibly basic hand tools if sensor replacement is required.
7. Do I need a professional to fix code C1694?
If you have an advanced OBDII scan tool and understand the calibration process, you can attempt the repair yourself. Otherwise, it’s best to seek help from a qualified technician.
8. Can an alignment issue trigger code C1694?
Yes, improper wheel alignment can affect the steering angle sensor readings and trigger this code. An alignment check may be necessary.
9. Will disconnecting the battery clear code C1694?
Disconnecting the battery may clear the code temporarily, but if the underlying issue is not resolved, the code will return.
10. How much does it cost to fix code C1694?
Repair costs vary but typically range from $100 to $300, depending on whether the issue requires just a calibration or replacement of the steering angle sensor.
