B356A:02 Code - Vehicle Direction Warning Switch Circuit Short to Ground
Quick Answer
The lane departure warning system is controlled by the Active Safety Control Module. Common causes include Faulty Vehicle Direction Warning Switch, Vehicle Direction Warning Switch harness is open or shorted, Vehicle Direction Warning Switch circuit poor electrical connection. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
- What it means
- B356A:02 indicates Vehicle Direction Warning Switch Circuit Short to Ground.
- Common causes
- Common causes include Faulty Vehicle Direction Warning Switch, Vehicle Direction Warning Switch harness is open or shorted, Vehicle Direction Warning Switch circuit poor electrical connection.
- Severity
- High - diagnose this code as soon as possible.
- Can I drive?
- Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.
Code B356A:02 Description
When the Frontview Camera module is operating and can detect the lane markings, the Frontview Camera module will request via serial data communications that the instrument panel cluster illuminate the green lane departure ready–to–assist indicator. If the Frontview Camera module detects that the vehicle has crossed a lane marking without the turn signal being used, the module will request that the instrument cluster flash the yellow lane departure warning indicator. An audible warning may also sound three times, or the haptic seat (if equipped) may pulse when the yellow Instrument Cluster indicator is flashing. The driver can select between audible or haptic alerts in the vehicle personalization menu. The Diagnostic Trouble Code (DTC) will be set when the Active Safety Control Module has detected a short to ground for more than 10 s.
What are the Possible Causes of the DTC B356A:02?
- Faulty Vehicle Direction Warning Switch
- Vehicle Direction Warning Switch harness is open or shorted
- Vehicle Direction Warning Switch circuit poor electrical connection
- Faulty Frontview Camera Module
- Faulty Active Safety Control Module
How to Fix the DTC B356A:02?
Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.
What is the Cost to Diagnose the Code?
Labor: 1.0
To diagnose the B356A:02 code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.
Need more information about the B356A:02 code?
Need more information on how to fix the B356A:02 code? Get Access to Factory Service Manuals
Need Help with the Code?
Get the B356A:02 code diagnosed by a professional: Find a repair shop in your area
Frequently Asked Questions about B356A:02 Code
1. What does OBDII code B356A:02 mean?
Code B356A:02 indicates a short to ground in the vehicle direction warning switch circuit, which is responsible for signaling directional warnings.
2. What are the common symptoms of code B356A:02?
Symptoms may include malfunctioning direction warning signals, illuminated warning lights on the dashboard, or failure of other related systems.
3. What causes the B356A:02 code to appear?
The code is typically caused by damaged wiring, a faulty direction warning switch, or corrosion in the circuit connections.
4. Can code B356A:02 affect vehicle safety?
Yes, this code can impact vehicle safety by preventing directional warning signals from functioning properly, which could lead to miscommunication with other drivers.
5. How do I diagnose the B356A:02 code?
Use a diagnostic scanner to confirm the code, then visually inspect the wiring, connectors, and the direction warning switch for damage or corrosion.
6. What tools are needed to fix code B356A:02?
You may need a multimeter to check for continuity, basic hand tools for removing and replacing components, and electrical repair supplies like connectors or wiring.
7. Does the B356A:02 code always require part replacement?
Not always—if the issue is caused by a shorted wire or loose connection, repairing or securing the wiring may resolve the problem without replacing components.
8. How much does it cost to fix code B356A:02?
Costs vary depending on the exact cause, but minor wiring repairs may cost under $100, while replacement of the direction warning switch can cost $150-$300 including labor.
9. Can I clear code B356A:02 with a scanner without fixing the issue?
You can clear the code temporarily, but it will likely reappear unless the underlying problem is addressed.
10. Is code B356A:02 specific to certain vehicles?
This code can appear on vehicles equipped with OBDII systems that utilize a vehicle direction warning switch, but the exact circuit design may vary between manufacturers.
