AutoCodes - OBDII Code List - B1516 CHEVROLET

B1516 CHEVROLET - Battery Current Sensor

Repair Importance Level: 3/3
Repair Difficulty Level: 3/3    What is this?
Table of contents

B1516 CHEVROLET Possible Causes

  • Faulty Battery Current Sensor
  • Battery Current Sensor harness is open or shorted
  • Battery Current Sensor circuit poor electrical connection
  • Faulty Body Control Module (BCM)

How do I fix code B1516 CHEVROLET?

Check the "Possible Causes" listed above. Visually inspect the related wiring harness and connectors. Check for damaged components and look for broken, bent, pushed out, or corroded connector's pins.
Connect Your Car To The Future

Tech Notes

B1516 08: Battery Current Sensor Signal Invalid
B1516 66: Battery Current Sensor Wrong Mounting Position

Cost of diagnosing the B1516 CHEVROLET code

Labor: 1.0

The cost of diagnosing the B1516 CHEVROLET code is 1.0 hour of labor. The auto repair labor rates vary by location, your vehicle's make and model, and even your engine type. Most auto repairs shops charge between $75 and $150 per hour.

Possible Symptoms

  • Engine Light ON (or Service Engine Soon Warning Light)

B1516 CHEVROLET Description

The Battery Current Sensor is a 3-wire hall effect current sensor. The Body Control Module (BCM) supplies 5 V and ground to the battery current sensor. The battery current sensor measures the amount of current flowing to or from the battery, and supplies a Pulse Width Modulation (PWM) signal to the BCM.
