B0560 2017 Chevrolet Silverado Code - Engine RPM Input Circuit Signal Invalid

Quick Answer

The Audio Amplifier receives a discrete pulse-width modulated engine speed signal from the Engine Control Module. Common causes include Faulty Audio Amplifier, Audio Amplifier harness is open or shorted, Audio Amplifier circuit poor electrical connection. Severity is High - diagnose this code as soon as possible. Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

What it means: B0560 2017 Chevrolet Silverado indicates Engine RPM Input Circuit Signal Invalid.
Common causes: Common causes include Faulty Audio Amplifier, Audio Amplifier harness is open or shorted, Audio Amplifier circuit poor electrical connection.
Severity: High - diagnose this code as soon as possible.
Can I drive?: Driving is not recommended if the warning light is flashing, the engine runs poorly, or safety-related symptoms are present.

Save to My Repairs My Repairs

AI answers can be wrong. Verify repairs with testing. Open full chat

Code Popularity 288

How popular is this code, among other codes? Low

Repair Importance Level

Urgent (Diagnose now) (3 / 3)

Repair Difficulty Level

Advanced (Pro) (3 / 3)

What is this?

Table of contents Created and updated by William Orellana on Nov 16, 2022

Description
Possible Causes
How To Fix
Cost to Diagnose
FAQs
Comments
Add Comment

💬 Need more help? Ask Coddy for instant answers — it's free!

Code B0560 2017 Chevrolet Silverado Description

The Audio Amplifier receives a discrete pulse-width modulated engine speed signal from the Engine Control Module. The Audio Amplifier uses the engine RPM signal for operating active noise cancellation. The Diagnostic Trouble Code (DTC) will be set when the discrete engine speed signal to the Audio Amplifier indicates the engine speed is less than 300 RPM or greater than 9000 RPM.

OBDII Code B0560 2017 Chevrolet Silverado - Engine RPM Input Circuit Signal Invalid - AutoCodes.com — B0560 2017 Chevrolet Silverado Code - Engine RPM Input Circuit Signal Invalid

What does this mean?

What are the Possible Causes of the DTC B0560 2017 Chevrolet Silverado?

Faulty Audio Amplifier
Audio Amplifier harness is open or shorted
Audio Amplifier circuit poor electrical connection
Faulty Engine Control Module (ECM)

How to Fix the DTC B0560 2017 Chevrolet Silverado?

Review the 'Possible Causes' above and visually examine the corresponding wiring harness and connectors. Check for damaged components and inspect connector pins for signs of being broken, bent, pushed out, or corroded.

What is the Cost to Diagnose the Code?

Labor: 1.0

To diagnose the B0560 2017 Chevrolet Silverado code, it typically requires 1.0 hour of labor. Rates vary by location, vehicle, and shop. Many shops charge between $80–$150 per hour; dealerships and metro areas may be higher, independents may be lower.

Need more information about the B0560 2017 Chevrolet Silverado code?

Need more information on how to fix the B0560 2017 Chevrolet Silverado code? Get Access to Factory Service Manuals

Need Help with the Code?

Get the B0560 2017 Chevrolet Silverado code diagnosed by a professional: Find a repair shop in your area

About the author: William Orellana is a Master Mechanic and Mechanical Engineer with over 30 years of experience diagnosing and repairing vehicles. Learn more about his background.

Frequently Asked Questions about B0560 2017 Chevrolet Silverado Code

1. What are the common symptoms of OBDII code B0560 in a 2017 Chevrolet Silverado?

- Common symptoms include erratic engine operation, rough idling, stalling, and potential issues with the vehicle's transmission shifting smoothly.

2. What does the OBDII code B0560 indicate in a 2017 Chevrolet Silverado?

- The code B0560 indicates an issue with the Engine RPM Input Circuit Signal being invalid, usually due to a malfunction in the circuit or a faulty sensor.

3. What are some possible causes of OBDII code B0560 in a 2017 Chevrolet Silverado?

- Possible causes include a faulty engine speed sensor, damaged wiring or connectors in the circuit, or issues with the engine control module (ECM).

4. How can I diagnose the OBDII code B0560 in my 2017 Chevrolet Silverado?

- Diagnosing this code typically involves checking the engine speed sensor's wiring and connectors for damage, testing the sensor's functionality, and inspecting the ECM for any faults.

5. Can I still drive my 2017 Chevrolet Silverado with the OBDII code B0560 present?

- It is not recommended to drive the vehicle with this code present, as it can lead to further damage and potential safety hazards. It is best to address the issue promptly.

6. How can I repair OBDII code B0560 in my 2017 Chevrolet Silverado?

- Repairing this code usually involves replacing a faulty engine speed sensor, repairing damaged wiring or connectors, or reprogramming the ECM if necessary.

7. Will resetting the OBDII code B0560 in my 2017 Chevrolet Silverado make it go away permanently?

- Simply resetting the code may temporarily clear the error, but if the underlying issue is not addressed, the code is likely to reappear once the problem resurfaces.

8. Is it safe to continue driving my 2017 Chevrolet Silverado if the check engine light is on due to code B0560?

- It is recommended to avoid driving the vehicle with the check engine light on, as it indicates a potential issue that needs attention to prevent further damage or safety risks.

9. Can a DIY enthusiast fix OBDII code B0560 in a 2017 Chevrolet Silverado?

- Depending on their skills and experience, a DIY enthusiast may be able to diagnose and repair this code by following the vehicle's service manual and using the necessary tools.

10. How much can I expect to pay for repairing OBDII code B0560 in my 2017 Chevrolet Silverado at a professional auto repair shop?

- Repair costs for this code can vary depending on the exact cause of the issue and the labor rates of the repair shop, but it is advisable to budget for sensor replacement or wiring repairs.
